Merida Silex 200

£1,000.00

With an incredibly lightweight smooth welded frame and full carbon forks, the Scultura will take your race aspirations to the next level. Lateral stiffness is especially high giving maximum pedal efficiency and acceleration out of the saddle.

Product Code: mersilex200

Availability: Out of Stock

Available Options

  • SMART ENTRY:
    Cables, housings and brake hoses are clamped under tension to prevent rattling. All inlets are completely interchangeable to deal with Di2, hydraulic hoses, brake cable and gear cable housings etc.
    PROLITE 66 TRIPLE BUTTED ALUMINIUM:
    Our proven high-end aluminium (6066) is extremely light and durable. Using triple butted wall thicknesses and hydroforming technology, we tune the aluminium tubes to give the best possible stiffness to weight ratio.
    HYDRO FORMING SYSTEM (HFS):
    Tubes are inserted into negative moulds and a hot emulsion of water and oil is forced through at pressure, enabling them to be formed into complex shapes.
    SMOOTH WELDING:
    Sometimes called ‘double pass welding’, a second pass over the weld gives a clean organic look to the frame. At first glance you’ll be convinced it is carbon.
    CHAINSTAY POST MOUNT:
    Post mounted calipers fit directly for a strong and light connection whilst positioning the caliper on the chainstay within the rear triangle gives it extra protection and better distribution of braking forces.
Colour

Black

Bike Brands

Size

Medium

  • FRAME: Lightweight 6066 triple butted and hydroformed aluminium frame with upright gravel geometry and tapered headtube for stable but nimble handling
  • FORK: Silex CF2; Tapered steerer; carbon
  • HUBS: VP 173SB; 100x12 mm axle; 32 spoke; 6 bolt front and VP 273SB; 142x12 mm axle; 32 spoke; 6 bolt rear with Merida Expert SL rear axle including removable lever; 6/4mm allen key
  • RIMS: Merida Comp SL; 17 mm inner width; 22 mm deep; aluminium
  • SPOKES: Black stainless
  • INNER TUBES: Lite 48mm Presta valve
  • TYRES: Maxxis Rambler; 700x38C; Kevlar bead - folding; TR; EXO
  • SHIFTERS: Shimano Sora
  • DERAILLEURS: Shimano Sora; GS
  • CHAINSET: FSA Omega; 48-32 teeth
  • CASSETTE: Shimano CS-HG200; 11-32 teeth; 9 speed
  • BOTTOM BRACKET: FSA PF86 MegaExo
  • CHAIN: KMC M99
  • PEDALS: Not included
  • BRAKES: Shimano Sora levers with Promax DSK-330R; Mechanical disc brakes and 160mm rotors
  • GRIP: Merida Road Comp
  • HANDLEBAR: Merida Expert GR; aluminium
  • STEM: Merida Comp CC; aluminium; 31.8 mm diameter; -6 degree rise
  • HEADSET: Merida M2331
  • SADDLE: Merida Comp CC; V-mount
  • SEAT CLAMP: Merida Expert
  • SEAT POST: Merida Comp CC; aluminium; 30.9 mm diameter; 0 mm layback
  • HARDWARE: Stainless
  • WHEEL SIZE: 700c
  • GEARS: 18
  • WEIGHT: 10.45 kg
